Name: XCHT Frameset
Brand: Jibe Cycleworks
Price: 1000.0 USD
Availability: OutOfStock

Jibe XCHT carbon fiber frame in the color El Dorado. A raw carbon with gold decals.

$1,000.00

Low stock - 1 item left
Backordered, shipping soon

If we don't have your preferred size, color, or parts specification in stock, please email support@jibebike.com for soonest availability.

Jibe XCHT Frameset Includes:

Jibe carbon XCHT frame
Rear thru-axle
FSA Orbit integrated headset
Black alloy seat post collar
Silver alloy threaded brake post inserts
Pre-installed waterbottle bolts
Pre-installed rear derailleur hanger
Rubber stopper inserts and cable guides

Frame Specifications:

Press fit 90 Bottom Bracket
Frame material: Full Carbon Fiber
Internal cable routing (RB/DP/RD)
E-type chain guide mount
Max Tire: 29" x 2.5
Boost 148mm O.L.D. x 12mm Thru axle
Frame weight: 2.5 lbs (size medium)
Chain line: Boost 52mm chain line, 168mm Q-Factor
Head tube: Integrated Tapered 1-1/8" to 1-1/2"
Front fork travel: 100mm/120mm
Recommended fork offset: 51mm
Rear brake: 160mm post mount, 180mm max rotor
Seat post: 30.9mm

FRAME WARRANTY-

Lifetime Guarantee – Jibe Bikes are guaranteed to be free of defects in materials and workmanship for the original owner. Jibe Cycleworks will either repair or replace at its discretion any part it determines to be defective. This warranty is non-transferable.

NO FAULT REPLACEMENT -

Should your Jibe product be involved in a crash or other non-warranty situation, Jibe Cycleworks will make replacement parts available at a minimum charge to the original owner for the life of the product. Jibe Cycleworks does this at its sole discretion and reserves the right to refuse this service.

PPF/ Paint Protection Film: Custom cut to perfectly fit your frame. Locally wrapped in SLC, UT. 7 mil paint protection film on frame body with a 10 mil paint protection film on the down tube for tailgate and extra chip protection.

[{"id":46399855853853,"title":"Small \/ Cannonball Grey","option1":"Small","option2":"Cannonball Grey","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Small \/ Cannonball Grey","public_title":"Small \/ Cannonball Grey","options":["Small","Cannonball Grey"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399855886621,"title":"Small \/ Cool Grey","option1":"Small","option2":"Cool Grey","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Small \/ Cool Grey","public_title":"Small \/ Cool Grey","options":["Small","Cool Grey"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399855919389,"title":"Small \/ Black Cherry","option1":"Small","option2":"Black Cherry","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Small \/ Black Cherry","public_title":"Small \/ Black Cherry","options":["Small","Black Cherry"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399855952157,"title":"Small \/ Chameleon Copper","option1":"Small","option2":"Chameleon Copper","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Small \/ Chameleon Copper","public_title":"Small \/ Chameleon Copper","options":["Small","Chameleon Copper"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":48815178252573,"title":"Small \/ El Dorado","option1":"Small","option2":"El Dorado","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Small \/ El Dorado","public_title":"Small \/ El Dorado","options":["Small","El Dorado"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399855984925,"title":"Medium \/ Cannonball Grey","option1":"Medium","option2":"Cannonball Grey","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Medium \/ Cannonball Grey","public_title":"Medium \/ Cannonball Grey","options":["Medium","Cannonball Grey"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856017693,"title":"Medium \/ Cool Grey","option1":"Medium","option2":"Cool Grey","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Medium \/ Cool Grey","public_title":"Medium \/ Cool Grey","options":["Medium","Cool Grey"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856050461,"title":"Medium \/ Black Cherry","option1":"Medium","option2":"Black Cherry","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Medium \/ Black Cherry","public_title":"Medium \/ Black Cherry","options":["Medium","Black Cherry"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856083229,"title":"Medium \/ Chameleon Copper","option1":"Medium","option2":"Chameleon Copper","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Medium \/ Chameleon Copper","public_title":"Medium \/ Chameleon Copper","options":["Medium","Chameleon Copper"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":48815178285341,"title":"Medium \/ El Dorado","option1":"Medium","option2":"El Dorado","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Medium \/ El Dorado","public_title":"Medium \/ El Dorado","options":["Medium","El Dorado"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856115997,"title":"Large \/ Cannonball Grey","option1":"Large","option2":"Cannonball Grey","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Large \/ Cannonball Grey","public_title":"Large \/ Cannonball Grey","options":["Large","Cannonball Grey"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856148765,"title":"Large \/ Cool Grey","option1":"Large","option2":"Cool Grey","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Large \/ Cool Grey","public_title":"Large \/ Cool Grey","options":["Large","Cool Grey"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856181533,"title":"Large \/ Black Cherry","option1":"Large","option2":"Black Cherry","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Large \/ Black Cherry","public_title":"Large \/ Black Cherry","options":["Large","Black Cherry"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856214301,"title":"Large \/ Chameleon Copper","option1":"Large","option2":"Chameleon Copper","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Large \/ Chameleon Copper","public_title":"Large \/ Chameleon Copper","options":["Large","Chameleon Copper"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":48815178318109,"title":"Large \/ El Dorado","option1":"Large","option2":"El Dorado","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Large \/ El Dorado","public_title":"Large \/ El Dorado","options":["Large","El Dorado"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856247069,"title":"Extra Large \/ Cannonball Grey","option1":"Extra Large","option2":"Cannonball Grey","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Extra Large \/ Cannonball Grey","public_title":"Extra Large \/ Cannonball Grey","options":["Extra Large","Cannonball Grey"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46399856279837,"title":"Extra Large \/ Cool Grey","option1":"Extra Large","option2":"Cool Grey","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Extra Large \/ Cool Grey","public_title":"Extra Large \/ Cool Grey","options":["Extra Large","Cool Grey"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":47399542423837,"title":"Extra Large \/ Black Cherry","option1":"Extra Large","option2":"Black Cherry","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Extra Large \/ Black Cherry","public_title":"Extra Large \/ Black Cherry","options":["Extra Large","Black Cherry"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":47399545536797,"title":"Extra Large \/ Chameleon Copper","option1":"Extra Large","option2":"Chameleon Copper","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"XCHT Frameset - Extra Large \/ Chameleon Copper","public_title":"Extra Large \/ Chameleon Copper","options":["Extra Large","Chameleon Copper"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":48815178350877,"title":"Extra Large \/ El Dorado","option1":"Extra Large","option2":"El Dorado","option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"XCHT Frameset - Extra Large \/ El Dorado","public_title":"Extra Large \/ El Dorado","options":["Extra Large","El Dorado"],"price":100000,"weight":9072,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}]

XCHT Frame

Bought an XCHT frame for a NICA race build for my daughter. Love the frame and I am more than satisfied. Super light and the paint job is excellent. People at Jibe were great to deal with and answered the few questions I had quickly. Will be buying another Jibe XCHT frame for my son as he gets into NICA.
